< Sash Clamps

Aluminium Sash Clamps - 900mm - Pack of 6

Regular price £90.00
Regular price £0.00Sale price £90.00
In Stock for delivery by
Order within
These aluminium sash clamps are chosen over traditional steel sash clamps for their incredibly light weight and ease of use. Large ductile iron jaws exert high pressure without deforming, and are tapered towards each other for true parallel clamping.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 28,595 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Aluminium Sash Clamps - 900mm - Pack of 6
Regular price £90.00
Regular price £0.00Sale price £90.00
  • 3 Year Warranty
  • Class leading clamping force of 8000N, for rock solid work holding
  • Extruded aluminium U-section is resistant to bowing and twisting
  • Cast iron jaws are tapered for parallel, non-slip clamping under pressure
  • Flat bottom design allows clamps to stand unaided during glue ups
  • Incredibly light, easily repositioned and carried with just one hand
These aluminium sash bar clamps have a 900mm clamping capacity and are perfect for large capacity clamping jobs such as door and window frames, kitchen units and table and cabinet tops. They are incredibly light and easy to use meaning they are chosen over traditional steel sash bar clamps for a multitude of projects. Constructed from flat aluminium beam with large surface area ductile iron heads and tails they can exert high pressure without deforming and are also tapered towards each other to enable true parallel clamping. The clamp has flat feet to allow it to stand, unaided, on the workbench which will prove especially useful for most glue ups.

The clamp is fully adjustable as the tail can be locked off in 25mm increments and the lead screw has a travel of 45mm. The smooth running rolled acme threaded bar provides easy and rapid movement of the clamp head. Weighing only 0.92kgs they can still exert an impressive 8000N of clamping force. Because of the aluminium construction an additional benefit is that the bar will not mar the surface of your workpiece, which could be the case with steel sash clamps. Supplied in packs of 6. We have been seriously impressed with the quality of these clamps. ©
  • BrandRutlands®
  • Product CodeR3006X6
  • Clamping Force8000N
  • Clamping Capacity900mm
  • Bar Size35mm x 20mm
  • Weight0.92kg
  • Overall Length1070mm
  • Jaw Dimensions43x40mm

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

We accept all major credit cards and mobile payment methods. Visit our Payment page.

We will happily accept returns within 30 days. For more information about returns, visit our Returns page.


Customer Reviews

Based on 17 reviews
Trevor M.
Nice Light Clamps

I have previously used Paramo cramp heads on bars and found them excellent. The only problem is they are very heavy and messing about moving the bar around to get the initial length was a bit of a nuisance.
I bought these based on seeing Paul Sellers using similar ones. I had always thought this style of sash cramp was rather cheap by comparison but having seen his modifications decided to go for them. I am very pleased as they are much quicker to set up and the absolute strength of the cramp heads isn't actually needed for most jobs.
These are far better as they are quick, lighter which helps with smaller and lighter projects and the aluminium is a bonus because PVA glue just chips off after each job.
Paul's modifications are worthwhile and I am very pleased with them. Definitely better than using cramp heads for most jobs.

Martin M.
The muts nuts

For the price, they are the dogs bollocks!

well sturdy and worth the price when discounted

Easy to use. Sturdy clamps. When discounted, cheaper than making your own pipe clamps.good length too

Sam A.
Lovely light clamps

Great light clamps, makes moving panel glue ups alot more managable than steel clamps. As others had mentioned, I was disappointed that the fixing pins stop the screw thread so movement so thread movement is reduced. That being said, I am able to clamp what i need fine. Will keep an eye out for more on offer.

Martyn P.
Good quality

Good quality at a great price
