Planer Thicknesser

Regular price £335.00
Regular price £0.00Sale price £335.00
In Stock for delivery by
Order within
Combining planing and thicknessing functions in a smaller footprint, a powerful high torque motor drives the precision machined cutting block, rotating two high speed steel blades at 8,500rpm, ensuring an ultra-smooth even thickness on soft, hard and composite woods.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 28,581 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Planer Thicknesser
Regular price £335.00
Regular price £0.00Sale price £335.00
  • 3 Year Warranty
  • Precision machined, cast aluminium surface tables are ribbed to maintain flatness
  • 8500rpm cutter block leaves a smooth, ripple free finish on hard and softwoods
  • Adjustable planing depth, up to 2mm per pass
  • Rigid alloy fence can be titled through 45°
  • Dust extraction facility with industry standard 63mm port
For the workshop where space is at a premium, the combination of a planer and thicknesser is favoured, as they take up far less valuable space. The principle of a planer thicknesser is that the surface planer flattens and squares a board and the thicknesser gets the board to an even thickness.

The surface tables on this machine are precision machined from cast aluminium and are heavily ribbed underneath to maintain flatness. The twin blade cutter block is powered by a 1250W high torque motor, rotating at 8500rpm ensuring an extremely smooth, ripple free finish on both hard and softwoods. The rigid alloy fence supports the work and can be titled through 45°, whilst the full width Suva guard gives maximum protection. As an additional safety feature a micro switch prevents the planer from operation if the Suva guard is not correctly fitted. When surface planing you can control the depth of cut from 0mm to 2mm in one pass.

In thicknessing mode the in feed and out feed rollers take hold of the wood and move the wood through the cutter block at a consistent feed rate. The thicknessing bed features a stainless steel plate and will accept workpieces up to 200mm wide by 120mm deep, allowing for up to 2mm to be planed in one pass. When connected to a vacuum, fine dust is drawn from the cutter block via the dust chute, which is positioned on the surface table. The dust chute doubles as a blade guard and features a micro switch to prevent operation if not fitted. Weighing 25kg this is a solid, well engineered planer thicknesser that leaves an excellent finish and is supplied with a pair of HSS planer blades. ©
  • BrandRutlands®
  • Product CodeR1602
  • Voltage230V
  • Power1250W
  • Dimensions800mm x 460mm x 440mm
  • Weight25kg
  • No Load Speed8,500rpm
  • Surface Table200mm x 735mm
  • Planing Depth0-2mm
  • Fence Size520mm x 120mm
  • Blade MaterialHSS
  • Thickness Table Size250mm x 200mm
  • Thicknessing Planing Capacity6mm to 120mm
  • Feed Rate6m/min
  • Dust Port Diameter63mm

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

We accept all major credit cards and mobile payment methods. Visit our Payment page.

We will happily accept returns within 30 days. For more information about returns, visit our Returns page.


Customer Reviews

Based on 16 reviews
perfect piece of equipment

where to start. i have been after one of these for a while now but the price tag put me off. i did not want to go for another brand that it available elsewhere. so i waited. when it came down to £200 in the black friday deal i snapped it up. boy am i glad i did. 10 mins setting up. 10 mins working out the adjustments. 10 mins swapping out the extractor/safety unit. first the planer. ran some pallet wood along it. kept running it to take of .5mm to 1mm. after a couple of passes, you could se it starting to smooth out. once i finished the wood needed no sanding. it was super smooth. i then flipped over to the Thicknesser. once i got the adjustment right again through multiple small passes the finish is superb. no need to sand. the fence is about 1deg out. but it isnt a great problem for me & i will play with it to get it square. as others have said the extraction/safety device is a bit fiddly. but it only takes a couple of mins to do, it he fence is slid fully towards the planer adjusting knob. all in all i am delighted with this purchase. it is solid, well built, fantastic price i got it for. the bed is totally level. no gaps anywhere on it. using a set square & spirit level. it was delivered on time exactly when Rutlands said it would be. it even comes with a push block, and a spare drive belt. rutlands have really excelled themselves with this piece of equipment. if you are in the market for a planer/thicknesser. buy it

Will J.
Great machine for the budget

Compact, well built and a great performer. Don’t confuse this with similar looking but cheaper tools, even if some casings are shared, having had both, this is miles ahead. The fence isn’t quite as robust as I’d like, however with a little bit of time spent setting up it runs straight and true. So far I have used this on oak, larch, C16 Pine and Tulipwood for a guitar body. I am very happy with the results, great finish and if you are careful feeding your work piece into the rollers, snipe is minimal to nonexistent! I got this with the Black Friday offer at an absolute steal, but would’ve been happy to pay full price. Excellent customer service as always. Thank you again Rutlands!

Overall a decent machine for the price...

Overall a decent machine for the price. Planing does a good job when you limit it to 0.5mm, anything more causes a fair amount of tear out. Thicknessing is ok but the pressure rollers have a tendency to grab the timber quite aggressively, causing the cutters to slightly gouge the start and end of the piece of timber, which have to be sanded or re-planed to remove the gouge, so not perfect.

Geoff G.
Having used a large Sedgwick planer many years ago...

Having used a large Sedgwick planer many years ago I was a lisle sceptical about a machine of this size. So far it has performed very well. I bought a number of lengths of rough cut 4 x 2's in 6 foot lengths and trued them on the surface table. Then I thicknessed all four faces removing roughly 2mm per face. The first time I used it I did not connect my extractor and the finish was not ultra smooth. When I did connect the extractor the finish was excellent. Dust gets trapped in the recess between the planer knives and the cutter block when not using an extractor. Overall very pleased with this planer and I would definitely invest again.

Peter B.
It was delivered on time about a week ago...

It was delivered on time about a week ago. Installation was trivial. Initial results are very promising. It cuts cleanly and accurately. Chip extraction works very well, although it is somewhat tedious when changing over from planing to thicknessing. However at the price this is more than acceptable. I would strongly recommend this product.

Planer Thicknesser

Smooth, ripple free finishes

The twin blade cutter block rotates at 8,500rpm, leaving a smooth finish when planing and thicknessing both hard and softwoods.
