Pocket Hole Jig

Regular price £80.00
Regular price £0.00Sale price £80.00
In Stock for delivery by
Order within
Incredibly fast and easy to use, simply set the height of the drilling block to match the width of your wood. The drilling block can be used independently from the base of the jig, for jointing long work pieces or for repair work where an existing joint cannot be dismantled.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 28,564 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Pocket Hole Jig
Regular price £80.00
Regular price £0.00Sale price £80.00
KEY FEATURES
  • 3 Year Warranty
  • Tool steel guide bushes eliminate wear and play, for a true and consistent drilling line
  • Simply position the jig body along the scale, matching the stock thickness
  • Powerful, non-slip clamping without damage or crushing of the timber fibres
  • Integrated vacuum port for optimum dust removal and improved drilling performance
  • Ready to use, supplied with drill and driver bits, depth stop, screws and plugs
FULL DESCRIPTION
Pocket hole jigs allow you to produce incredibly strong, precise and clean joints when making kitchen cabinets, wardrobes, book cases and other furniture. Pocket hole joints require no glue and the joints can be easily dismantled at any time. This new pocket hole jig is in a class of its own when it comes to build quality, accuracy and ease of set up.

The key features found on other leading brands of jig have been combined to create one exceptional pocket hole jig. The toggle clamp and guide bushes are manufactured from tool steel, precision CNC machined to ensure both clamping and drilling accuracy. A series of four holes in the base allow you to mount the jig directly to your work bench for maximum stability.

The drilling block features two hardened steel bushes to accept and guide the HSS stepped drill bit at the correct angle. The clamp is easily applied using the large lever and you can vary the clamping pressure subject to the density of your wood, to prevent damage or crushing of the timber fibres. The rubber face of the clamp features a hatched design which strengthens the grip on the workpiece without causing surface damage. A vacuum port held in position by rare earth magnets offers effective dust removal and improved drilling performance when connected to an extraction system.

Set up is incredibly simple. To set the height of the drilling block you measure the width of your wood and then raise the drill block by the width of the wood, using the etched graduated metric scale. To set the drill depth stop collar you lay your drill bit against the horizontal scale and align it to the measurement that shows your wood width, then slide and lock on the depth collar. The drilling block can be used independently from the base of the jig if required for jointing extremely long work pieces. This ready to go pocket hole kit contains the full steel jig, titanium coated stepped drill bit, depth collar, square driver bit, screws and plugs. Beautifully finished in matte black, this is an exceptional pocket hole jig that we highly recommend for precise, fast set-up pocket jointing. ©
SPECIFICATIONS
  • BrandRutlands®
  • Product CodeR6000
  • Dimensions320mm x 100mm x 70mm
  • Minimum Wood Thickness12mm
  • Maximum Wood Thickness38mm
  • Bit Length150mm
  • Bit Diameter9.5mm
SHIPPING & PAYMENT

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.

Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.

REVIEWS

Customer Reviews

Based on 12 reviews
92%
(11)
8%
(1)
0%
(0)
0%
(0)
0%
(0)
L
Luke
A PROPER POCKET HOPE JIG

This replaced a cheap and cheerful jig that only barely got the job done. This jig is the business! The clamp is perfect and fast, the dust extraction port makes a massive difference to the speed of drilling the holes plus the provided drill bit is of good quality and cuts well.

S
Steven
THIS WAS A FAR BETTER USE OF MY MONEY THAN SMALL TRINKETS

Bought this recently to finish the cabinetry work on my campervan. This clamping jig has single handedly helped me construct the most solid cabinets and seating ever. Before this I had an old and rusted single pocket hole piece that needed an extra clamp (or two) - always wiggling to either side, needing to stop and re-adjust to get through soft ply. This jig is worth the value hands down. For the time it has saved me and the piece of mind knowing each clamp on this jig will hold true, I'm glad I bought this. Most of Rutland's tools look decent enough; haven't had this tool long but I'm almost certain it'll stay around with me for many years. Powder coating, stainless materials and the rubber clamp design are great. (Prevents damage to softer materials with simple adjustment and the rubber clamps specific design unlike the lazy alternative manufacturers) The measurement adjustment works a treat and is accurate. The countersunk steel plate will find it's very own place in my workshop (when I get one!) You can see by these photos it's well manufactured. Last thing I'll add is that my furniture in the van is rock solid. I can push the kitchen units and bed, they don't move a mm but entire van does. It's now one solid unit. I put it down to using this jig honestly. I used inferior tools like my single pocket hole on the last camper build. My cabinets squeaked and the joints slowly started coming apart. This tool has been a night and day difference, thanks Rutland's 👍

B
Ben
SOLID TOOL

This pocket hole jig is certainly well built compared to other equivalent jigs. Solid and weighty giving it stability that is handy for larger parts it can hold

I
Iain B.
Awesome bit of kit the drill bit it comes with is ...

Awesome bit of kit the drill bit it comes with is dead sharp and bores into wood easily, can't believe how easy it is use and how great the results are. Made some quality looking speaker cabinets with concealed joints

C
Colin R.
Excellent jig...

Excellent jig. Much larger than I anticipated making it very solid and stable.

Pocket Hole Jig

Sets up in seconds

Simply raise the drill block by the width of the wood, using the etched metric scale.
