Router Table - Lift & Motor
- Shop with confidence with our 3 Year Warranty
- Rated excellent by Trustpilot based on 30,289 reviews
- Over 2.5 million Rutlands® premium woodworking tools sold worldwide
- 3 Year Warranty
- Powerful 1500 watt motor maintains consistent speed under load
- Variable speed range of 8000 to 27000rpm, to easily match the speed to the router bit
- Hand wheel smoothly controls the router bit height along the 40mm of travel
- In the event of a power cut the NVR switch will remain off until you press the 'On' button
- Produce accurate, angled cuts using the supplied mitre gauge
The new 2024 model of this best selling powered router table has a new high torque variable speed motor that maintains its rotational speed under load to ensure a consistent fine finish to the routed workpiece.
A motorised router table has one distinct advantage over standard router tables; it comes with its own motor meaning you don't have to tie up your hand held router in your table. This router table is perfectly sized for any workshop and can be bench mounted or floor standing when mounted on the optional stand.
The 1500W motor is electronically controlled and gives a speed range from 8,000 - 27,000rpm; perfect for all diameters of router cutter. For added versatility, this table is supplied with both 1/4" and 1/2" collets giving you the freedom to carry out most routing projects. Cutter height is controlled using the hand wheel at the front of the table. This gives a seamless rise and fall along the full 40mm of travel and the cutter height can be set and locked off anywhere along this. Also at the front, the power switch is easy to access should you need to switch the machine off in a hurry.
Made from steel pressings, the 600mm wide by 460mm deep table top features a full length accessory slot allowing it to accept the supplied mitre gauge or feather boards. The adjustable fence also features accessory tracks allowing it to accept the included feather boards. A 70mm dust port to the rear of the fence gives you dust extraction at source for cleaner working. Router bit holders on the left and right hand side of the stand provide ample storage and quick access to 1/4" and 1/2" shank router bits. Supplied with 1/2" and 1/4" collets, fence, 3 x feather boards and a mitre gauge, this router table is excellent value for money.
Specifically designed for the R5105 Powered Router Table, the optional R5106 workstand turns the router table from a bench mounted machine to a floor standing one allowing you to keep your work bench free for other jobs. Supplied flat for ease of delivery, this stand requires assembly by the user and should take around 30 minutes to assemble. The design and shape of the stand means it is strong without being too heavy and fits the motorised router table perfectly. ©
- BrandRutlands®
- Product CodeR5105
- Voltage230V
- Power1500W
- Weight20kg
- Variable Speed Range8,000 - 27,000 rpm
- Collet Diameters1/2" and 1/4"
- Dust Port Diameter70mm
- Router Bit Travel0mm - 40mm
- Maximum Router Bit Diameter80mm
- Dimensions360mm x 600mm x 460mm
UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.
Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.
Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.
Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.
Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.
Customer Reviews
This is a robust, quality router table. Definitely value for money and I would recommend it
This is a great product and exceptional value for money. Can’t fault it.
Thanks Rutlands
Had this a few weeks now. I can't fault it. Runs quiet , nice and compact. Does everything you'd want it to. I've bought a few Rutlands tools lately.. very good quality.
Purchased to replace the aging workshop unit, the main selling point was the 1/4 and 1/2 Collect options.
Build Quality is very high and simple enough to use. Speed settings are very good and gives the user a lot of precision for the unit.
The Lift Motor is easy and simple to use and the locking collet is much better than on most units ive used before and very user friendly.
The instructions for putting it together arent the clearest but easily worked out :)
This really is a remarkable bit of kit for the money you pay. I ummed and ahhed about it for a while but decided to replace my homemade table with this and couldn’t be more glad that I did.
The table is study and well made and the lift mechanism is everything you could hope for for the price. Bit changes are simple and effortless and the variable speed is a dream. This thing feels powerful and tremendously safe with the feather boards and guard. Almost can’t fault it…
The only downsides are the lack of instructions, but you only need to assemble the fence which, with the aid of YouTube isn’t that hard. The bit storage is also a bit (pun intended) useless as the router bits are loose and can fall through into the space behind the panel. There’s also no on board storage for the bit change spanner. But you’re paying £200 for a full router table system that is portable and powerful so I’m glad that the thought has gone into the router and table rather than the nice-to-have accessories.
Wouldn’t hesitate to recommend this to others.
Portable and powerful
High torque, variable speed motor maintains constant speed under load, for a super fine finish on hard, soft and composite woods.
