< Sash Clamps

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Regular price £100.00
Regular price £0.00Sale price £100.00
In Stock for delivery by
Order within
These aluminium sash clamps are chosen over traditional steel sash clamps for their incredibly light weight and ease of use. Large ductile iron jaws exert high pressure without deforming, and are tapered towards each other for true parallel clamping.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 28,564 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Aluminium Sash Clamps with Feet - 1200mm - Pack of 4
Regular price £100.00
Regular price £0.00Sale price £100.00
KEY FEATURES
  • 3 Year Warranty
  • Class leading clamping force of 8000N, for rock solid work holding
  • Extruded aluminium U-section is resistant to bowing and twisting
  • Cast iron jaws are tapered for parallel, non-slip clamping under pressure
  • Extra wide feet ensure stable, free standing clamping during glue ups
  • Incredibly light, easily repositioned and carried with just one hand
FULL DESCRIPTION
These aluminium sash clamps with supporting feet are an upgrade on the traditional aluminium sash clamps while still maintaining the original's features and benefits. The upgrade being the addition of cast iron feet at both ends of the clamps. The feet allow the clamps to stand freely and securely on your work surface. This means your workpiece can be clamped during glue ups without the risk of the clamps ever falling over. Constructed from a sturdy flat aluminium beam with large surface area cast iron heads and tails that measure 50mm high x 45mm wide they can exert high pressure without deforming and are also tapered towards each other to enable true parallel clamping.

The clamps are fully adjustable as the tail can be locked off in 25mm increments and the lead screw has a travel of 45mm. The smooth running rolled acme threaded bar provides easy and rapid movement of the clamp head and is wound by a crank handle to maximise the force exerted. The feet elevate the clamp adequately so that the handle can be wound without obstruction. These clamps have a large clamping capacity of 1200mm and because of the aluminium construction an additional benefit is that the bar will not mar the surface of your workpiece. Weighing only 1.38kgs they still exert an impressive 8000N of clamping force. Supplied in packs of 4. A welcome improvement on our traditional aluminium sash clamps. ©
SPECIFICATIONS
  • BrandRutlands®
  • Product CodeR3011X4
  • Clamping Force8000N
  • Clamping Capacity1200mm
  • Bar Size35mm x 20mm
  • Weight1.38kg
  • Overall Length1450mm
  • Foot Width55mm
  • Jaw Dimensions50x45mm
SHIPPING & PAYMENT

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.

Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.

REVIEWS

Customer Reviews

Based on 21 reviews
100%
(21)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
D
Dom F.
Aluminium Sash Clamps with feet

Yet again, excellent service. Very prompt delivery at a very reasonable rate.
I have never been disappointed with any of the products I have bought and will continue to use Rutlands as my first place to buy woodworking goods.

E
Eric F.
These things are great! Just used them to

These things are great! Just used them to glue some reclaimed wood into an outdoor cabinet / bench. Absolutely brilliant!

J
Joe S.
For the price point a very well made

For the price point a very well made and sturdy sash clamp, does exactly what is says on the tin for a great price

A
Andy B.
I consider these very good value...

I consider these very good value. Light enough to handle with ease and do the job no questions asked, will now see how the parallel jaw clamps compare

A
A H.
Opted for these over the regular aluminium clamps ...

Opted for these over the regular aluminium clamps and from my limited time with them so far they've been brill. The feet give it that extra bit of stability when clamping up panels. Already eyeing up my next set of clamps.

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Class leading clamping force

Exerts up to 8000N of clamping force, to deliver best in class workholding.

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4

Aluminium Sash Clamps with Feet - 1200mm - Pack of 4
