Parallel Jaw Clamps - 1200mm x 95mm - Pack of 4
- Shop with confidence with our 3 Year Warranty
- Rated excellent by Trustpilot based on 30,212 reviews
- Over 2.5 million Rutlands® premium woodworking tools sold worldwide
- 3 Year Warranty
- Class leading clamping force of 6000N, for rock solid work holding
- Perfectly parallel jaws ensure precise alignment of workpieces
- Hardened, cold drawn steel bar will not bend or flex under load
- Fast action Acme thread allows easy exertion of maximum clamping force
- Removable no-mar protection pads for easy glue removal
The clamps have an anti slip system which means that no matter how much pressure is exerted, the jaws will not slip on the bar and slide backward. A foot at the non working end of the bar allows for the clamp to stand upright un-aided making it ideal for clamping flat panels. The large acme screw thread ensures maximum clamping pressure is achieved with the minimum number of turns of the handle.
The extra large jaws allow for the use of fewer clamps and are extremely beneficial when clamping large, flat workpieces. The jaws are made from ductile cast iron and are encased in glue resistant polypropylene, the no mar protection pads can be removed to aid the removal of dried glue. The 29mm wide rail is made from I section C45 hardened steel to prevent the clamp from bending or flexing under load.
These are parallel jaw clamps that can evenly exert up to 6000N of clamping force. They have maximum clamping capacity of 1200mm, a jaw width of 45mm with a throat depth of 95mm. The clamp can easily be converted into a spreader with spreading capacity of 260mm to 1385mm. Each clamp is also supplied with 2 protective bar pads to ensure the workpiece does not meet the bar and become marked. Supplied in packs of 4. ©
- BrandRutlands®
- Product CodeR3016X4
- Clamping Force6000N
- Clamping Capacity1200mm
- Throat Depth95mm
- Bar Size29mm x 9mm
- Weight3.85kg
- Spreading Capacity260-1385mm
UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.
Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.
Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.
Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.
Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.
Class leading clamping force
Exerts up to 6000N of clamping force, to deliver best in class workholding.
