Phenolic Radius & Aperture Jig

Regular price £130.00
Regular price £0.00Sale price £130.00
In Stock for delivery by
Order within
Engineered from solid grade, high-performance phenolic, this jig is designed for routing a range of curved apertures and radii when creating curved worktops and fitting curved cabinets. The jig is precision CNC machine cut to provide a huge range of internal and external radii, straight, square and 45° cuts, as well as 26mm & 35mm hinge recesses.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 29,722 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Phenolic Radius & Aperture Jig
Regular price £130.00
Regular price £0.00Sale price £130.00
KEY FEATURES
  • 3 Year Warranty
  • Provides a huge range of internal and external radii for curved worktops
  • Produces cabinet hinge recesses, as well as square straight edge cuts and 45° end cuts
  • Each radius has corresponding pin holes and engraved lines for quick and easy setup
  • CNC machined to +/- 0.02mm accuracy with laser-engraved instructions on the surface
  • Exceptional dimensional stability and warp resistance; totally resistant to moisture
FULL DESCRIPTION
This worktop jig is engineered from solid grade, high-performance premium phenolic known for its exceptional strength, stability and warp resistance - as well as being totally water and liquid resistant. Budget jigs made from laminated composite can warp and lose stability due to moisture absorption and temperature change leading to inaccurate cuts and joints. The extremely durable, anti-friction phenolic allows your router to glide smoothly through the cut without snagging. Inferior jigs made from less durable composite material can wear over time leading to imperfections in the surface and inaccurate cuts and joints.

This jig is ideal for routing a range of curved apertures and radii for creating curved worktops and fitting curved cabinets. Precision CNC machine cut with +/- 0.02mm accuracy it will ensure you achieve precise curves every time. With six radii options (250mm, 150mm, 100mm, 80mm, 60mm, 40mm) suitable for both internal and external cuts this jig is perfect for both kitchen worktops as well as furniture and cabinet radius cut applications. In addition this jig enables straight cuts up to 820mm, square cuts, 26mm & 35mm hinge recesses and the corners allow for 150mm, 100mm, 50mm external radii and 45° precise end cuts.

This radius & aperture jig complements the Rutlands® phenolic worktop jig perfectly. Laser-engraved essential instructions and diagrams on the jig surface allow for very quick setup and ease of use. The engravings are cut into the phenolic surface meaning they will not wear under constant friction from the router - providing long lasting clarity. A comprehensive user manual is also included alongside four 10mm precision fit ABS aligning pins. To use this jig you will need a ½" hand router, router bit (diameter: 12.7mm, height: 50.8mm), 30mm guide bush and clamps.

Achieve consistent and precise cuts and curves every time from a jig that is moisture and warp resistant. ©
SPECIFICATIONS
  • BrandRutlands®
  • Product CodeR5069
  • Dimensions989mm x 395mm x 12mm
  • Weight7kg
  • Radius Curves250mm, 150mm, 100mm, 80mm, 60mm, 40mm
  • Maximum Straight Cut820mm
  • Hinge Recesses26mm, 35mm
  • Corner Radii50mm, 100mm, 150mm
  • End Cut45°
SHIPPING & PAYMENT

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.

Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.

REVIEWS

Customer Reviews

Based on 3 reviews
100%
(3)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
L
Liam S.
Good kit

This is 2nd jig ive bought from Rutlands. Not used it yet but don't expect any issues. Well made premium jig. Site mates are impressed . 1st jig is great.
Rutlands need to sell protective bags! I've had to buy a Tend bag for my Rutland jigs!!☹

T
Tim S.
Previously bought a jig made from MDF from a well known retailer at a very good price.

Previously bought a jig made from MDF from a well known retailer at a very good price. Left it in the back of my van for a couple of days and it swelled around the edges. Retailer would not give me my money back so i had to bin it. Paid a lot more for this one but the quality is in a different league. Very heavy and well finished - should last me out

S
S S.
Very well made and finished jig.

Very well made and finished jig. It's heavy but very solid with no bowing at all.
