Plunge Saw with 1.4m Guide Rail
- Shop with confidence with our 1 Year Warranty
- Rated excellent based on 14,000 product reviews
- Over 3.5 million Rutlands® premium tools sold worldwide
- 1 Year Warranty
- Powerful 1200W high torque motor ensures consistent rotational speed under load
- Ultra-thin, 1.6mm kerf blade removes less material, drastically reducing cut time
- Large bevel range of -1° to 47°, with anti-tip base plate to prevent lifting and tipping over
- Scoring cut mode provides a shallow, 2.5mm preliminary cut to minimise chipping and tearout
- Blade change mode locks the blade height for easy blade changes using the onboard hex key
- Supplied with 1.4m guide rail with full length phenolic strips, for smooth, low friction travel
The Rutlands® corded plunge saw comes with a 1.4m guide rail and features a high torque, 1200W motor that maintains consistent speed and power under load. The saw features a bevel cutting range of -1° to 47° for under/overcutting, and the anti-tip lock within the baseplate locks the saw onto the guide rail, preventing the saw from lifting or tipping over. A 2-position depth stop shows the current depth of cut both with and without a guide rail. The maximum depth of cut with a guide rail is 54mm at 90° and 38mm at 45°.
A three position blade mode dial allows quick switching between scoring cuts, free plunging and blade change modes. The scoring cut setting locks the depth of cut to 2.5mm, providing a shallow, preliminary pass on melamine or veneer faced boards to minimise chipping and tear-out. The free plunge mode is selected for normal operation, whilst the blade change mode locks the blade height in position to perform quick and easy blade changes using the onboard hex key. The supplied ultra-thin, 1.6mm kerf blade is specially designed to remove less material whilst cutting, reducing the load on the motor whilst allowing you to work faster.
The 1.4m single piece guide rail features two full length rubber strips on the underside, protecting the workpiece from damage whilst increasing friction to prevent movement. A sacrificial rubber strip on the edge of the rail acts as a splinter guard, applying downward pressure onto the material to minimise tear-out. Once trimmed to the blade kerf on first use, the splinter guard indicates the exact cutting edge, allowing the guide rail to be positioned precisely at the scribe mark. The guide rail is compatible with other leading brands. Included is a 165mm, 48T thin kerf TCT blade, 1.4m guide rail, blade change key and dust port adaptor. ©
- BrandRutlands®
- Product CodeR1647
- Voltage230V
- Power1200W
- Weight5.4kg
- No Load Speed6,000rpm
- Bevel Cutting Angles–1° to 47°
- Maximum Cutting Capacity at 90°54mm
- Maximum Cutting Capacity at 45°38mm
- Saw Blade Diameter165mm
- Saw Blade Tooth Count48T
- Saw Blade Kerf1.6mm
- Saw Blade Bore20mm
- Dust Port Diameter34.5mm
- Cable Length2.1m
UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £8.50. Visit our Shipping page.
Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.
Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.
Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.
Gift Cards
Rutlands® gift cards are delivered instantly by email to the email address entered at checkout and contain a unique code for use at checkout. You can forward the email and code directly to the recipient. Visit our Gift Card page for more information.
Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.
Customer Reviews
Great quality item, (not sure what that previous negative review was all about), I’ve used this saw with the track endlessly, and every cut is straight and effortless. If this plunge saw died today, I would replace it tomorrow without hesitation with the same model. Wry happy customer.
Superb plunge saw and guide rail, which produces clean and precise cuts accurately. Quieter than my previous saws, and minimal dust (when connected to a dust collection system). Easy to use and well made.
It makes clean straight cuts, but I wish they had included clamps for the rail.
A. Fantastic piece of equipment just arrived along with a number of other great Rutland products.
Fast and efficient delivery at a fantastic price price and after sales service highly recommended
Great addition to my tools, always wanted a saw with the guide it makes life so much easier. Saw is a great weight and easy to handle
Clean, feather-free cuts
Scoring mode takes a 2.5mm preliminary cut to eliminate chipping & tearout.
