Router Bit - Surface Trim & Tenon
Router Bit - Surface Trim & Tenon
Router Bit - Surface Trim & Tenon
Router Bit - Surface Trim & Tenon
Router Bit - Surface Trim & Tenon
< TCT Router Bits

Router Bit - Surface Trim & Tenon

Regular price From £40.00
Regular price £0.00Sale price From £40.00
In Stock for delivery by
Order within
These surface trim & tenon router bits feature 2 down shear blades for a producing crisp tenon shoulder, and 2 up shear blades for a clean face to the tenon, also used for the machining and clearing of large areas of material. Each bit features diamond ground, micro-grain tungsten carbide tipped blades for long lasting hardness and superior edge retention.
Select Option
  • D=25mm H=20mm L=60mm S=1/4" £40.00
  • D=50mm H=20mm L=70mm S=1/2" £75.00
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 30,193 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Router Bit - Surface Trim & Tenon
Regular price From £40.00
Regular price £0.00Sale price From £40.00
KEY FEATURES
  • 3 Year Warranty
  • Used for the machining and clearing of large areas of material, or producing tenons
  • Micro-grain tungsten carbide ensures long lasting hardness and superior edge retention
  • Perfectly balanced, vibration free bodies for a smoother cut
  • Shear angle blades slice the wood for a feather free finish
  • Anti kick back design for maximum operator safety
FULL DESCRIPTION
TCT Router Bits
Each router bit features diamond ground, micro-grain tungsten carbide tipped blades. This tighter micro-grain structure means the blades offer long lasting hardness and superior edge retention. The body of each bit has been turned and then milled with uncompromising precision from a single piece of 4140 high tensile steel to give perfect balance for reduced vibration and therefore smoother cuts. 4140 steel has been chosen because of its toughness, high fatigue strength, and abrasion and impact resistance. The tungsten carbide tips are then brazed onto the bodies using induction to create an extremely strong joint that safely holds under the high stresses that occur when routing. The router bits are suitable for use on softwoods, hardwoods, veneers, laminates and composite materials.

Surface Trim & Tenon Bits
Surface trim & tenon bits are used for the machining and clearing of large areas of material, as well as producing tenons or wide rebated edges. These bits feature 4 cutting edges, 2 with down shear blades for a producing crisp tenon shoulder, and 2 up shear blades for a clean face to the tenon.

Superior Finish and Performance
The shearing angle of the cutting edges ensure they remain in constant contact with the workpiece to allow a smoother, slicing cut which eliminates tear-out and gives a mirror finish. The bits feature right hook angles which further enhances the cut due to the fast removal of chips. These bits feature an anti-kickback design which limits the feed rate of the material being cut to decrease the likelihood of a kickback, meaning each bit conforms to strict German DIN standards to ensure maximum operator safety. ©
SPECIFICATIONS

    Please select an option above

SHIPPING & PAYMENT

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.

Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.

REVIEWS

Customer Reviews

Based on 10 reviews
100%
(10)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
P
Peter B.
Router bits for Router sled

I received three router flattening bits . Two four blade and one six blade .
I used the six blade today and it was perfect I will have to get another as a spare . I can safely assume the other two will be just as good .
Ones again well done Rutland

D
Darren B.
Value for money

Nice smooth finish

A
Alan B.
70mm router Bit - Surface Trim & Tenon

Excellent quality, only used on mrmdf so far but it cut very smoothly

A
Adam B.
I love this bit excellent and just what

I love this bit excellent and just what i needed.

M
Martin B.
Well packaged & presented

Well packaged & presented, and most importantly, with me the next day. As for the results, I'm very pleased so far & have managed to find profiles not offered by other suppliers. Will no doubt be back for more.
