Aluminium Sash Clamps - 1500mm - Pack of 6

Regular price £110.00
Regular price £0.00Sale price £110.00
In Stock for delivery by
Order within
These aluminium sash clamps are chosen over traditional steel sash clamps for their incredibly light weight and ease of use. Large ductile iron jaws exert high pressure without deforming, and are tapered towards each other for true parallel clamping.
  • Shop with confidence with our 3 Year Warranty
  • Rated excellent by Trustpilot based on 28,581 reviews
  • Over 2.5 million Rutlands® premium woodworking tools sold worldwide
Aluminium Sash Clamps - 1500mm - Pack of 6
Regular price £110.00
Regular price £0.00Sale price £110.00
KEY FEATURES
  • 3 Year Warranty
  • Class leading clamping force of 8000N, for rock solid work holding
  • Extruded aluminium U-section is resistant to bowing and twisting
  • Cast iron jaws are tapered for parallel, non-slip clamping under pressure
  • Flat bottom design allows clamps to stand unaided during glue ups
  • Incredibly light, easily repositioned and carried with just one hand
FULL DESCRIPTION
These aluminium sash bar clamps have a 1500mm clamping capacity and are perfect for large capacity clamping jobs such as door and window frames, kitchen units and table and cabinet tops. They are incredibly light and easy to use meaning they are chosen over traditional steel sash bar clamps for a multitude of projects. Constructed from flat aluminium beam with large surface area ductile iron heads and tails they can exert high pressure without deforming and are also tapered towards each other to enable true parallel clamping. The clamp has a flat bottom to allow it to stand, unaided, on the workbench which will prove especially useful for most glue ups.

The clamp is fully adjustable as the tail can be locked off in 25mm increments and the lead screw has a travel of 45mm. The smooth running rolled acme threaded bar provides easy and rapid movement of the clamp head. Weighing only 1.25kgs they can still exert an impressive 8000N of clamping force. Because of the aluminium construction an additional benefit is that the bar will not mar the surface of your workpiece, which could be the case with steel sash clamps. Supplied in packs of 6. We have been seriously impressed with the quality of these clamps. ©
SPECIFICATIONS
  • BrandRutlands®
  • Product CodeR3008X6
  • Clamping Force8000N
  • Clamping Capacity1500mm
  • Bar Size35mm x 20mm
  • Weight1.25kg
  • Overall Length1670mm
  • Jaw Dimensions43x40mm
SHIPPING & PAYMENT

UK Shipping
UK orders placed before 4pm will be delivered the next working day with shipping costing £7. Visit our Shipping page.

Outside of UK Shipping
We ship worldwide to over 200 countries. The total amount you pay includes all applicable customs duties & taxes. We guarantee no additional charges on delivery. Shipping cost and delivery time shown at checkout. Visit our Shipping page.

Click & Collect
Simply select Pick up on the checkout, and we will email you when you order is ready for collection at our distribution centre in Bakewell. Visit our Click & Collect page.

Payment
We accept all major credit cards and mobile payment methods. Visit our Payment page.

Returns
We will happily accept returns within 30 days. For more information about returns, visit our Returns page.

REVIEWS

Customer Reviews

Based on 3 reviews
33%
(1)
67%
(2)
0%
(0)
0%
(0)
0%
(0)
m
martin
Sash clamps

very well constructed considering how light they are to handle. easy to use single handed and a very useful size.
a great buy on a daily price drop deal

K
Kevin L.
Ideal for lightweight clamping jobs...

Ideal for lightweight clamping jobs. Slight design fault. The heads are now held in place with two pins to attach it to the aluminium bar, which means the threaded clamping side has lost half of the usable thread. On a couple of my clamps, the threaded clamp only has about 22mm of travel but the other end locks at approx 25-26mm intervals, which means you have to pack it out with a piece of wood to take up the slack. Apart from that, they are a handy clamp for the price.

J
James G.
You get what you pay for...

You get what you pay for. Amazing price, £100 for 6 clamps. Very useful. However I am giving it 4 stars as they are constructed of 1.6mm thick aluminium which flexes a lot (too much) under pressure. I have another set by a different manufacturer that use 3mm thick aluminium and they are vastly better. So when using them, you must balance the clamps opposite each other by having one each side of your material to negate the flex somewhat. The maximum jaw travel is only 20mm due to the protruding rivets that block the thread travel which is barely enough if, say, you are gluing up multiple boards to make a larger panel using biscuits. Would definitely benefit from more useable thread. Maximum opening width is 1523mm and they adjust very easily. Overall I think they are excellent for the money and I would buy them again, as at under £17 each they are a bargain, but don't expect to pull poor joinery together as they don't have the clamping pressure without deforming.
